Innovative, adaptable internal doorsets benefit all stakeholders, from architects through to installers.
Modulo Doorsets have been designed to reduce change on site
Modulo Doorsets have up to 25mm of adjustment in each dimension ensuring perfectly-fitting doors in structural openings not perfectly formed. By stocking fully machined doors and frame set components with door leaves (along with the relevant ironmongery), thousands of Q-Mark® certified doorset combinations can be picked, pre-hung, packed and despatched within hours. The perfect timber doorset solution for internal, residential and commercial doorsets!
Speed up and Simplify Internal Doorsets:
Simple to Specify
Suitable for commercial doorsets , accommodation and refurbishment applications. Simple to select and specify, reducing design and planning costs.
Simple to Procure
Our unique pricing configurator makes door procurement simple offering competitively priced timber doorsets and strategic savings across your project.
Simple to Manufacture
Offsite manufacturing precision. Minimal lead times on timber doorsets from order placement to delivery, providing internal and commercial doors with world-class lead times.
Simple to Install
Modulo doorsets are pre hung doorsets which give you the flexibility to adjust with their impressive structural opening tolerance. Less time on site, no snagging or call backs.Modulo Doorset System
-
Pre-hung in Frame Help to overcome problems on-site, before they happen.
-
Pre-fitted Ironmongery All non-protruding components factory fitted for safe transportation.
-
Pre-mitred Architrave No cutting required on site.
-
Concealed Fix System Innovative Rapid-fit brackets for ease of installation.
-
Simple Installation Fit twice the amount of timber doors, compared to a standard doorset.
-
Compliance tested and certified Fire, smoke, acoustic and security tested to latest standards.
Door Leaf 44mm Blockboard core (as standard), stronger and lighter than chipboard. ABS lippings to the top and sides; either complimenting or contrasting colours, with no need for on-site trimming or finishing.
Door Frame 30mm thick with pre-installed smoke/sound gasket. Four standard widths; 85mm, 100mm, 120mm, 140mm in a ready to paint finish.
Architrave Pre-mitred with Hoffman clips for easy on-site assembly and simply pushed into frame groove to fit.
Vision Panel 7mm Pyrobelite fire-rated glass available in three layout configurations with either White or Oak beading.
Intumescent Strip & Seal Providing the required rating for fire doors.
Intumescent Strip & Seal Providing the required fire-rating.
Butt Hinges Satin Stainless Steel ball bearing hinges.
CE Certified Door Leaf Furniture Handles, Closers, Latches and Ancillaries available in satin Stainless Steel.
